The GT-10 Mineral model of the transient electromagnetic instrument is a transient electromagnetic instrument device developed and manufactured by Shenzhen Saiying Ground and Air Technology Co., LTD. This model is mainly applied in scenarios such as metal mineral exploration, geological structure, and groundwater exploration
Hardware advantages and features:：The lightweight "one-box" design and innovative integrated design combine the receiver, transmitter and power supply into one, significantly reducing the weight of the equipment and greatly enhancing the portability and efficiency of field operations.
Hardware advantages and features:：The capacity is doubled, the efficiency is doubled, the battery capacity is doubled, it supports continuous data collection of 400 points, significantly extending the fieldwork time and improving the operation efficiency.
Hardware advantages and features：Supporting precise mobile detection, the -8Pro operation terminal is equipped with an offline map and supports RTK positioning. It reduces the time and labor required to measure each point in traditional methods and improves work efficiency.
Hardware advantages and features：The central probe adopts a cylindrical design, which is more compact and lightweight, reducing the failure rate of the original soft coil. It replaces the traditional overlapping loop layout, greatly simplifying the construction process and enhancing terrain adaptability. Whether in mountainous or flat areas, it can provide accurate measurement results.
Software advantages and features：It supports the installation of an intelligent tablet computer operation terminal, simplifying the parameter setting process and making it easy to get started.
Software advantages and features：Remote data management, real-time data upload.
Software advantages and features：The equipment acquisition and processing software is equipped with advanced algorithms to efficiently handle large-scale datasets and quickly generate analysis results.
Software advantages and features：Through RTK technology, data can be integrated into IT systems in real time, ensuring the continuity and accuracy of the data.
Software advantages and features：The new generation of interpretation software system integrates data acquisition, processing, forward and inversion analysis, and automatic output of results, and supports on-site generation of interpretation result maps.
Software advantages and features：The device supports both wired and wireless bridging to achieve rapid data storage and transmission
The GT-10 transient electromagnetic instrument is mainly applied in mineral exploration and water and mineral prospecting in the middle and deep parts, and can detect depths ranging from 30 to 1300 meters. It is widely used in underground polymetallic deposits, water exploration, underground electrical stratification, delineation of underground water-filled karst caves and exploration of steeply inclined geological structures. Coal seams and coal seam mined-out (subsidence) areas and water-filled areas; The census and exploration of geothermal resources and oil and gas fields in high-resistance covered areas (such as carbonate rocks, igneous rocks and permafrost covered areas); Tunnel water exploration and geological structure tracing, etc. The workload of this transient electromagnetic method detection: Three measurement lines are laid along the ground, with a measurement point interval of 2 meters. Conduct exploration of goaf areas; The detection effect on underground low-resistance is obvious. Verified with the existing known goaf data, the effect is good.
| Project | Parameters |
| A/D converter | 32Bit |
| Dynamic range | 160dB |
| Sampling rate | 1μs、4μs、16μs、 |
| Number of acquisition channels | 2 |
| Background noise | 1μV |
| Voltage measurement range | -200V-200V |
| Voltage measurement resolution | ≤300nV |
| Measurement accuracy | 0.1% |
| Input gain range | 1/80-8000 |
| Minimum sampling interval | 4μs |
| Noise suppression | >100dB |
| Passband | 0-500kHz |
| Superposition times | 1-65535times |
| Computer system | PC104 industrial control computer, 8.4 "color LCD screen (full Windows operation interface) |
| Data storage | 2G (Scalable) |
| Storage capacity | ≥30000 |
| Data transmission | USB2.0 |
| Power supply | The built-in battery can ensure operation for more than 8 hours and can be externally connected to 9-18VDC |
| Size | 403mm×330mm×178mm (length × width × height) |
| Weight | 8kg |
| Working temperature | -10℃-50℃ |
